El Machete APT Group

Threat Actor ID

Grup AdıEl Machete,
CountryUSA
First Seen2014
MotivationInformation theft and espionage
MethodsMalware, Spearphishing
Other NamesAPT-C-43

Vision, Mission, and Motivation

Machete is a South American-based APT group operating since 2010. They are also known as APT-C-43. Attacks affecting many countries, especially Latin America, are carried out against high-profile organizations such as government agencies, law enforcement, telecommunications, and energy companies. Information theft and espionage are the primary motivations for the attacks. Various activities are carried out, such as capturing screenshots from compromised devices, capturing geolocation data, accessing webcams, copying sensitive data to a remote server, and keylogging.

The group, which frequently uses social engineering techniques such as including malware-laden documents and links in fake e-mails, is known to conduct extensive intelligence work on the target before carrying out the attack. It has been determined that actual military documents were used in phishing attacks by threat actors.

forged documents belong to el-machete
Figure 1: Forged documents belong to El-machete

Approximately 75 false documents belonging to the threat actor group were identified. The themes of the forged documents, which were mostly found to have been seized from previous attacks and repurposed for targeted phishing attacks, were related to military information ranging from national-level political issues concerning the victims and personnel assignments. It has also been observed that threat actors exploit the victim’s sense of fear and panic by using themes such as debt collection and subpoenas. As a result of the metadata analysis of these documents, it has been reported that they were created in 2000, 2006, 2011, 2013, 2014, 2015, 2016, and 2017.

The graphic below shows the format information and usage rate of the documents used by the threat actors.

el machete apt group
Figure 2: Format information and usage rate of the documents used by El-machete apt group

Targeted Countries

Upon the analysis of the documents used by the group, it was determined that the papers were primarily prepared in Spanish and Portuguese, and there were Spanish scripts in the malware used. It is possible to deduce that the Machete APT group explicitly targets countries that use these two languages.

spanish code example of el machete apt group
Figure 3: Spanish code example

The countries where the cyber espionage group operates, which generally targets Latin American countries with effective spearphishing techniques, are as follows.

  • Venezuelan
  • Russia
  • Cuba
  • Chinese
  • Belgium
  • Ecuador
  • Brazil
  • Spain
  • France
  • Colombia
  • Peru
  • Sweden
  • United States of America
  • Malaysia
targeted countries machete
Figure 4: Targeted countries

Operations

  • The group, which carried out a China-focused attack in 2014, forwarded Hermosa XXX.pps.rar, Suntzu.rar, El Arte de la guerra.rar, and Hot Brazilian XXX.rar files to its victims via fake e-mails. It was determined that the files with a total size of 3 MB and loaded with malware were created in 2008. When the attack targeting the Windows operating system was analyzed, clues were obtained that the attackers developed their infrastructure for Mac OS X and Android.
  • By 2018, a concealment layer was included in the malware used in attacks against targets, using Zlib compression and base64 algorithm. In this way, most security products could not detect the updated malware to increase the success rate in targeted attacks.
  • In 2019, threat actors carried out an attack targeting the Venezuelan army. The phishing attack by threat actors has attracted attention due to the use of verified military documents obtained from previous episodes. After the attack, the group obtained sensitive data belonging to the army.
  • By 2022, the group targeted government institutions, energy, and finance sectors in Venezuela, Israel, Saudi Arabia, and Pakistan, using official documents on the ongoing war between Ukraine and Russia. Threat actors continued their espionage campaigns, using phishing techniques, screen capture, keylogging, and transmitting malware-laden documents that allow command execution on compromised systems to targets.

TTPs & Attack Lifecycle

Threat actors follow a series of stages that make up the attack lifecycle when they devise specific strategies to infiltrate an organization’s network and capture data. These stages are called techniques, tactics, and procedures (TTPs). It is essential to understand the techniques, tactics, and procedures to determine the purpose and motivations of threat actors and to ensure data and network security against actual attacks.

This part of the content includes techniques, tactics, and procedures belonging to the APT-C-43 group.

TacticTactic IDTechnique
Initial AccessT1192T1193• Spearphishing Link•Spearphishing Attachment
ExecutionT1204T1053• User Execution•Scheduled Task
PersistenceT1158T1053• Hidden Files and Directories•Scheduled Task
Defense EvasionT1027T1045

T1036

• Obfuscated Files or Information•Software Packing

• Masquerading

Credential AccessT1145T1081• Private Keys•Credentials in Files
DiscoveryT1049

T1120

T1083

T1217

T1010

• System Network Connections Discovery

• Peripheral Device Discovery

• File and Directory Discovery
Process Discovery

• Browser Bookmark Discovery

• Application Window Discovery

CollectionT1115T1005

T1025

T1056

T1113

T1074

• Clipboard Data•Data from Local System

• Data from Removable Media

• Input Capture

• Screen Capture

• Data Staged

Command and ControlT1008T1105

T1071

• Fallback Channels•Remote File Copy

• Standard Application Layer Protocol

ExfiltrationT1020T1041

T1052

T1029

• Automated Exfiltration•Exfiltration Over Command and Control Channel

• Exfiltration Over Physical Medium

• Scheduled Transfer

Indicator of Compromises

GoogleUpdate.exe

Hash(SHA1)Definition
048C40EB606DA3DEF08C9F6997C1948AFBBC959BPython/Machete.F
2E8D8508096CAA38493414F6BA788D0041EA9E15Python/Machete.F
85BDD7D871108C737701AC30C14A2D343CBDEF94Python/Machete.D
8ED8CB784512F7DADD147347FC94E945FAF16338Python/Machete.F
9C413075AAB7EF7876B8DC8D7B7C1B9B96842C6EPython/Machete.A
AB8DD6B0CC950618589603012863B57F7ADB9D9BPython/Machete.A

Chrome.exe

Hash(SHA1)Definition
318496B58CF5052EFD49A95C721D9165278E9FCEPython/Machete.B
3BB345032B6D0226D6771BA65FE4DA0FAF628631Python/Machete.B
946A24DFBD0AE94209EF7C284D3F462548566A3CPython/Machete.B
984B9202A6DBD7D3DD696CAE1220338A68092DC9Python/Machete.B
EABD45D0A86113F5CCFF9FD292C1E482A5727815Python/Machete.B
F05BC018C90B560DC4932758956ADFFBC10588CEPython/Machete.B

GoogleCrash.exe

Hash(SHA1)Definition
204A2850548E5994D4696E9002F90DFCCBE2093APython/Machete.C
3792588EDC809270E6666A4677EC85A3400BA4CFPython/Machete.E
4899A2C2CECEB92D2CC4ED17D092D1D599379284Python/Machete.A
A42756280AA352F4612BED85AABF7F3267E676C2Python/Machete.E
A97CF05AD7F3102BDE45E4B4947ED435EFEA1968Python/Machete.E

RAR/7z SFX: Config + Payload

Hash(SHA1)Definition
00397DA69B8E748720AEDFD80D78166573C33EC8ders.exe
03929A5530639C1D9DBD395A298C59FD7EFF1DECchrome.sfx.exe
0922DEFB82FF1140BBE3481BAB27564BB966D50BChrOme_UpdAte.sfx.exe
0AC64E08E63601AD9D6A4EF019E5B374784AF80Achrome.sfx.exe
0BA5BCE133B50EF80FD9241C3EA5CB9135CA4EB1ders.exe
161629F63422AB34108854662313F87A278DD7F5chrome.sfx.exe
24752DAB28C3ADD4C31591F2EC480CE3CA83E0AApython27.exe
341F2EFA0FD11B4480D8503BFB81C62AF667D72Dchrome_Up.sfx.exe
4C130AA110B290A0CF4FF1C099EA2A705081A9CBChrome_Update.sfx.exe
50C23690C23EE070AD3A20FCED7311BFDF098833ders.exe
67ECBC1E9A66719C599E6DDED33A85F70DACA13Echrome.sfx.exe
6A69A2A2D4A2F8690B71386F0F092B04EA5A647DChrOme_UpdAte.sfx.exe
92C56AF6815597C0135C21EF5A35D41B0E2A460FPython_27.exe
9E52E1C015B97D4FB2CAC888F8FC69D729AF78F5finaser.aes
A48A71B9D1C00A683397F97C02E0DBB3F4606863ders.exe
B6E436A0FFF117A1C3D3D70947F62D4CAC66C95Eders.exe
C4ACCF6071F51ADE102190C6FA350435FC202654Python.27.exe
D5238CDE036EEFCC6D8D686B3A00247F27DA894CPython.27.exe
DDA105D8D894F73B16518D546270E4F783CB5178python27.exe
E85C1EF38C39B6087EA9AC8171DDD1416B9A5306python27.exe
FD52B10E9D4E5D343E589627444A6766357D5E47Security.exe

7z SFX: Decoy C+ Downloader

Hash(SHA1)Definition
52B680F472AE463436979DA325DB7AD64D5AF1EFMapa_monitoreo_WRF_ind02052018.scr
69109287D41C002FA70BB3D6238C4056B2B24B2FMapa_monitoreo_WRF_ind02052018.scr
89C0FDEED36A69099E935A590A103339B0CBE525Mapa_monitoreo_WRF_ind02052018.scr
9EA7832D83C74C839A49580B4211E627A24571BEPrograma Formacion en Contratacion Publica.scr
BFD0CBEF5B9C329792B38274474F04BD8109DF66RGMA0_1_629.scr
FB871AACA0DDCF2F009A2D11ECF672CFB61B7357CALENDARIO_ACTIVIDADES_COLCO_EC.scr
FDE89FCEC30FCAABB3D42ED87180843F3E760CD8Mapa_monitoreo_WRF_ind02052018.scr

RAR SFX: URL Config + Downloader

Hash(SHA1)Definition
9912BDBE08179122DC3797A2585D463573D1B5A504Down.exe
AB16808B5B4706B6265C5FF5FEF8B8460C8A51F84Down.sfx.exe
BDAAB0B356EC9FE61FEE1723E1DD52E39DDC669904Down.exe
DED6509458DF62D3CE60C68F3A2A87E59F1F96BEDown.sfx.exe

Downloader

Hash(SHA1)Definition
2B7404F6B0075BC1192D61D4AF135D521D5F08A3RdrCEF.exe
53102E57B40FEACB64566C26D101D9242DECE77CDown.exe
56E8743E0773286A4B9E055147D96D53A43BECA1Down.exe
71F69F04307C8F5675DCADEAA80B8C2B95691B01Down.exe
904137B61F1DED66C8CA76EBF198DEC1B638B5D4Down.exe
FBB485B40477F5A014E7096747B1B4A494CE50EFDown.exe

_hashlbi.pyw

Hash(SHA1)Definition
1B3723651E1D321D4F34F2A243D7751D17288257Python/Machete.G
7FFB9C7DA20C536B694E78538B65726EACB1B055Python/Machete.G
B1ADF4B46350FB801CE54DA9C93A4EF79674F3F5Python/Machete.G

_bsdbd.pyw

Hash(SHA1)Definition
0C33B75F6C4FC0413ABDBCDA1C5E18C907F13DC3Python/Machete.G
314D9B4C25DD69453D86E4C7062DCE6DEDDA0533Python/Machete.G
D4CF22F3DB78BDC1CEB55431857D88166CE677D4Python/Machete.G

_clypes.pyw

Hash(SHA1)Definition
26FB301AF7393B5E564B8C802F5795EDEBD7CECFPython/Machete.G
979859B5A177650EF0549C81FD66D36E9DEA8078Python/Machete.G
A07E38DF9887EA7811369CD72C57FD6D44523CD6Python/Machete.G

_elementree.pyw

Hash(SHA1)Definition
07E383E9FF04F587769845306DC4BFE75630BAAAPython/Machete.G
3B6F5CB20FF3AC0EE3813A68A937AAE92EBC46D3Python/Machete.G
56765B7511372A8E9BE017F48A764D141F485474Python/Machete.G
CF2DC40926D8747AEC572DFD711BBFD766AADB10Python/Machete.G

_mssi.pyw

Hash(SHA1)Definition
6B42091CA2F89A59F4E27E30ACDACF32EB83F824Python/Machete.G
708F159F2CFE22FF0C4464F2FEDAA0501868BDD8Python/Machete.G
DE639618B550DBE9071E999AAA5B4FC81F63A5A6Python/Machete.G

_multiproccessing.pyw

Hash(SHA1)Definition
0B6F61AF3E2C6551F15E0F888177EEC91F20BA99Python/Machete.G
76AABC0AF5D487A80BCBA19555191B46766139FAPython/Machete.G
7FF87649CA1D9178A02CD9942856D1B590652C6EPython/Machete.G
8692EB1E620F2BCDDAF28F0CB726CEC2AA1C230DPython/Machete.G
8AF19AA3F18CB35F12EE3966931E11799C3AC5A4Python/Machete.G
E1BC4EC7F82FA06924DC4B43FBBB485D8C86D9CDPython/Machete.G

Domains

  • koliast[.]com
  • tobabean[.]expert
  • u929489355.hostingerapp[.]com
  • u154611594.hostingerapp[.]com
  • 6e24a5fb.ngrok[.]io
  • f9527d03.ngrok[.]io
  • adtiomtardecessd.zapto[.]org
  • mcsi.gotdns[.]ch
  • djcaps.gotdns[.]ch
  • tokeiss.ddns[.]net
  • artyomt[.]com
  • lawyersofficial.mipropia[.]com
  • ceofanb18.mipropia[.]com

IP Addresses

  • 185[.]224[.]137[.]63
  • 156[.]67[.]222[.]88
  • 158[.]69[.]9[.]209
  • 142[.]44[.]236[.]215
  • 199[.]79[.]63[.]188
  • 109[.]61[.]164[.]33

Recommendations & Mitigations

Attacks by threat actors negatively affect the brand integrity of institutions/organizations by violating the security of systems. The measures that can be taken by an institution to ensure the security of critical data and minimize all risks are as follows:

  • To ensure the security of the accounts used against brute force attacks, strong passwords should be created, and each password created should be platform-specific. In addition, it is recommended to enable multi-factor protection on accounts used whenever possible. This will provide an extra layer of security.
  • E-mails and links that are considered suspicious should not be trusted. As seen in the Machete APT group we covered in the blog post, forwarding malware-laden documents to victims via fake emails is a social engineering technique frequently used by threat actors. In addition, to be protected from possible social engineering attacks, it is important to raise awareness and train the personnel of the institution/organization on this issue.
  • Make sure that the software used is up-to-date. Threat actors can compromise systems by using out-of-date vulnerable applications and software.
  • Provided software and applications from reliable sources, unknown websites should be avoided.
  • Comprehensive security products such as firewalls and antivirus programs should be used in order to be protected from possible attacks and to ensure the security of sensitive data. These products will protect individuals and institutions from various risks, such as malware and phishing attacks, or reduce the effects of attacks.

Conclusion

The Machete APT group carries out carefully prepared attacks on targets that can be considered very important, although many threat actors are less known than the group. Although it has not been found to exploit any zero-day vulnerabilities, the group carries out cyber-attacks with advanced phishing techniques and malware after performing extensive intelligence work on the target and gathering information.

The Brandefense Threat Intelligence Team prepared this post, and it aims to raise awareness against cyber attacks carried out by Machete and similar threat actors. It is thought that it will be effective and useful to benefit from this post, which has been prepared so that potential targets can correctly determine the necessary precautions and priorities.

Download the IoCs from Brandefense Github Repository.
